- Hitch Weight
- 353 lb.
- 3,353 lb.
- 2,700 lb.
- 653 lb.
- Box Size
- Exterior Open Length
- 21' 2"
- Exterior Closed Length
- 21' 2"
- Exterior Closed Height
- 5' 8"
- Exterior Width
GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.
GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.
GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.
UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.
CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.
Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.
The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.
Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.
Note: Specifications are subject to change without notice.
Hard Side Standard Features
- White Fiberglass
- Autumn Wood Interior
- 12 Volt Water Pump
- Torsion EZ Lube Axles
- Hot Water Pkg w/ Outside Shower
- 3 Burner Indoor Range w/Cover
- Solar Prep On Frame
- Battery Box & Wiring
- 30 Amp Detachable Power Cord
- 35 Amp Converter
- LED Ceiling Lights
- Raised Panel Cabinet Doors
- Positive Latches & Catches On Doors & Drawers
- Wood Drawers with Full Extension Metal Guides
- Interior Floor Lights
- Durable Diamond Plate Front
- Fiberglass Laminated Roof
- 13" Radial Tires
- Electric Brakes
- 4 Stabilizer Jacks w/ Sand Pads
- Installed Door Step
- Large Folding Entry Door Grab Handle
- Courtesy Light on Front
- Outside Griddle
- Cable TV Ready
- Double 20 lb. Gas Bottles w/ Molded Cover
- Automatic Gas Regulator
- Hanging Wardrobe w/ 2 Shelves
- Takes 2" Ball
Hard Side Package
- 10K BTU Cool Cat Heat Pump (A/C & Heater)
- Create-A-Breeze Roof Vent Fan
- Spare Tire w/ Carrier & Cover
- CO Detector
- Water Filtration System
- Stereo w/ Outside Speakers
- Wi-Fi Booster w/ LTE Prep
- 1.7 CU - 12V Refrigerator w/ 100W Roof Solar Panel
- Power Front Jack
- 40 Amp Portable Solar Panel
